Stacking Monads can be somewhat confusing to get your head around. While looking around for a decent example, I came across this Gist by Decoherence on how to combine a ReaderT with a WriterT over some Monad.

I needed to use this stack as I was working with the IO Monad and needed some way to capture the outcomes of a computation (via a Writer) and also needed to supply the initial inputs (via a Reader).

While Reader and Writer Monads on their own seem easy to use, it can be somewhat daunting to try and figure out how to combine the transformer variations of these Monads over some other Monad.

I’m documenting my findings on how to use this stack here for anyone who might be also struggling to figure out how all this stuff hangs together. It is also for my future-self who might need a quick refresher.

Let’s start by looking at the type signature for the Reader Monad:

``r -> a``

The Reader Monad when given some resource, r from the environment will return a result of a.

The type variables defined are as follows:

• r = resource from the environment
• a = value returned

Next lets have a look at the type signature for a ReaderT Monad Transformer (MT):

``newtype ReaderT r m a = ReaderT { runReaderT :: r -> m a }``

This is less clear than the definition of the Reader Monad. As we’ll see below they are essentially very similar.

The type variables defined are as follows:

• r = resource from the environment
• m = the resulting Monad
• a = value returned in the Monad

The ReaderT MT has one extra type variable m which is a Monad. If we examine the ReaderT constructor we can see that it encapsulates a type very similar to that of the Reader Monad:

``````r -> m a -- ReaderT MT

When we see a ReaderT r m a we can mentally substitute it with a function of the type:

``r -> m a``

And when we see a function of the type `r -> m a` we can mentally substitute it with:

``ReaderT r m a``

Depending on the situation it might be easier to think in one of the above versions of the ReaderT MT.

Given a ReaderT r m a we can unwrap its value via the runReaderT method:

``runReaderT :: ReaderT r m a -> r -> m a``

Also given a simple Reader Monad (`r -> a`) we can lift it into a ReaderT MT with the reader or the asks function:

``reader,asks :: Monad m => (r -> a) -> ReaderT r m a``

``Monad m => Monad (ReaderT r m)``

This is important to know when using do notation with the ReaderT MT as each bind operation will result in a ReaderT r m and not a ReaderT:

``````someFunc :: ReaderT r m a
someFunc = do
return a -- this will be returned into ReaderT r m``````

If you need to wrap a value within a ReaderT MT use:

``ReaderT \r -> -- your value of (m a)``

This might all seem very confusing at the moment. These are different ways of lifting values into the transformer stack at different points. Once you start using the ReaderT MT this will become clearer.

Some other useful functions that work with the ReaderT MT are:

• ask - to retrieve the supplied resource
``ask :: Monad m => ReaderT r m r``
• local - to map a function on the resource before using it:
``local :: (r -> r) -> ReaderT r m a -> ReaderT r m a``
• mapReaderT - to change all components of the ReaderT MT except the input type (the inner Monad and result type):
``mapReaderT :: (m a -> n b) -> ReaderT r m a -> ReaderT r n b``

## Writer and WriterT

As we’ve not looked at the definitions of the Writer Monad and the WriterT MT let’s do that now. The Writer Monad is defined as:

``(a, w)``

The type variables defined are:

• a = return value
• w = log value (which has to be an Monoid)

The Writer Monad will return a pair of values; a result a along with an accumulated log w.

The WriterT MT is defined as:

``newtype WriterT w m a = WriterT { runWriterT :: m (a, w) }``

where the type variables defined are:

• a = return value
• m = the resulting Monad
• w = log value (which has to be an Monoid)

Both a and w are returned as a pair within the Monad m.

The WriterT constructor encapsulates:

``m (a, w)``

``````  (a, w) -- Writer Monad
m (a, w) -- WriterT MT``````

Some other useful functions that work with the WriterT MT are:

• runWriterT - to unwrap the value of a WriterT MT and return the result and the log:
``runWriterT :: WriterT w m a -> m (a, w)``
• execWriterT - to unwrap the value of a WriterT MT and return only the log:
``execWriterT :: Monad m => WriterT w m a -> m w``
• tell - to write a log entry into the WriterT MT:
``tell :: Monad m => w -> WriterT w m ()``
• listen - to change the result to include the log:
``listen :: Monad m => WriterT w m a -> WriterT w m (a, w)``
• pass - to run a function on the log to update it:
``pass :: Monad m => WriterT w m (a, w -> w) -> WriterT w m a``
• mapWriterT - to change all components of the WriterT MT (the inner Monad, result and log type):
``mapWriterT :: (m (a, w) -> n (b, w’)) -> WriterT w m a -> WriterT w’ n b``

Let’s also have a look at the MonadTrans typeclass. It defines one function called lift:

``lift :: Monad m => m a -> t m a``

that lifts a Monad into a MT. We can use this function to insert a Monad into a given transformer stack.

Phew! We’ve just had a whirlwind tour of some typeclasses and related functions. Now let’s have a look at an example of using a ReaderT/WriterT transformer stack.

Say we had some configuration about an external service, like its host and port. We might use a Reader Monad to supply that configuration to the program.

Let’s start by defining a type alias to a Map of String keys and values:

``````import qualified Data.Map.Lazy as M

type Config = M.Map String String``````

Let’s also define a serverConfig function to return our populated configuration from a list of key-value pairs:

``````serverConfig :: Config
serverConfig = M.fromList [("host", "localhost"), ("port", "7654")]``````

Let’s definite a function to read the host:

``getHost :: Reader Config (Maybe String)``

Given a Config this function will return the host name in a Just if present, or a Nothing if not.

It would could be implemented as:

``````getHost :: Reader Config (Maybe String)
getHost = do
return (Map.lookup "host" config)``````

First, the getHost function requests the Config instance from the environment using the ask function. It then looks up the “host” key from that config. Finally it lifts the Maybe value returned from the lookup function into the Reader Monad using the return function.

Let’s define a function to read the port:

``getPort :: Reader Config (Maybe Int)``

It would could be implemented as:

``````getPort :: Reader Config (Maybe Int)
getPort = do
return (Map.lookup "port" config >>= readMaybe)``````

This function is similar to getHost with the additional bind (>>=) operation to join together the value read from lookup with readMaybe. readMaybe tries to parse a String into a value of type Int in this case. If it successfully parses the value it returns a (Just Int) or if it fails it returns a Nothing. readMaybe is defined as:

``readMaybe :: Read a => String -> Maybe a``

``ReaderT r m a``

and we haven’t decided on what m is at the moment. I’ll demonstrate how we could have directly used a ReaderT MT to implement getHost and getPort later on.

Now that we’ve written functions to read the host and port, lets go ahead and use those values in a ReaderT MT along with a WriterT MT to log out the values we received from the configuration:

``getConfig :: ReaderT Config (WriterT String IO) ()``

Given a Config type as an input, the result returned will be in a WriterT MT with a log type of String with an inner Monad of IO and a value of unit () returned within IO. That sounds more complicated than it really is.

It’s implemented as:

``````getConfig :: ReaderT Config (WriterT String IO) ()
getConfig = do
let host = maybe "-" id hostM
port = maybe "-" show portM
_ <- log "\nConfig"
_ <- log "\n======"
_ <- log (printf "\nhost: %s" host)
_ <- log (printf "\nport: %s" port)
return ()``````

Let’s delve into the implementation of getConfig. The first two lines read the host and port into Maybe values from the configuration:

``````  hostM <- fromReader getHost

The next two lines covert the Maybe values for host and port into their String equivalents:

``````  let host = maybe "-" id hostM
port = maybe "-" show portM``````

The next four lines write String values to the log in order:

``````  _ <- log "\nConfig"
_ <- log "\n======"
_ <- log (printf "\nhost: %s" host)
_ <- log (printf "\nport: %s" port)``````

and the final line returns a Unit result into the ReaderT r m Monad:

``return ()``

Let’s look at the type definition of the fromReader function:

``fromReader :: Monad m => Reader r a -> ReaderT r m a``

``````fromReader :: Monad m => Reader r a -> ReaderT r m a

The runReader function is defined as:

``runReader :: Reader r a -> r -> a``

and unwraps the Reader Monad to a function (`r -> a`). The reader function (as defined previously) lifts a function from (`r -> a`) into the ReaderT MT. This seems like unnecessary work and ideally there should be an in-built function that does this for us.

Next let’s have a look at the log function:

``````log :: (Monad m, MonadTrans t, Monoid w) => w -> t (WriterT w m) ()
log = lift . tell``````

From the type definition of tell:

``tell :: Monad m => w -> WriterT w m ()``

we can see that we almost get the result we want:

``w -> WriterT w m ()``

We just need to lift the WriterT w m Monad into a Monad Transformer t and we can do that with the lift defined previously:

``lift :: Monad m => m a -> t m a``

which gives us:

``````w -> WriterT w m () -- tell

m a -> t m a -- lift
-- replacing m with (WriterT w m)
(WriterT w m) a -> t (WriterT w m) a
-- replacing a with ()
(WriterT w m) () -> t (WriterT w m) ()

-- combining lift . tell
w -> t (WriterT w m) ()``````

We can see that we are lifing some log w into a transformer stack t through the WriterT w m Monad.

We’ve come a long way and we’ve got everything setup as needed. The only thing left to do is run the transformer stack and reap our rewards. We can do that with the readWriteConfig function:

``````readWriteConfig :: IO ()

When running the stack, it is run from outside-in. So given a ReaderT (WriterT String m) a, we:

``r -> m a``

with runReaderT. This returns the result a in the inner Monad m which is a WriterT String m. Substituting the IO Monad for m and Unit for a returns a WriterT String IO (). We don’t care about the result of a - only the log.

1. Run the WriterT MT:
``m (a, w)``

with execWriterT. This returns the log w in the inner Monad m which is an m w. Substituting the IO Monad for m and String for w, returns an IO String.

1. Binding through from IO String to putStrLn gives us an IO (). The final output of running the above is:
``````Config
======
host: localhost
port: 7654``````

I previously mentioned that we could have written the getHost and getPort functions with a ReaderT MT instead of a Reader Monad. Here’s how we’d do that:

getHost2

``````getHost2 :: Monad m => ReaderT Config m (Maybe String)
getHost2 = -- same as getHost``````

Notice that the only difference between getHost and getHost2 is the addition of a new type variable m which is a Monad:

``````getHost  ::            Reader  Config   (Maybe String) -- Reader Monad

And since we are working with Monads in both cases, the implementation code remains unchanged! So just by changing the type definition of the getConfig method we can go from a Reader Monad to a ReaderT MT!

getPort2

``````getPort2 :: Monad m => ReaderT Config m (Maybe Int)
getPort2 = -- same as getPort``````

getConfig2

``````getConfig2 :: ReaderT Config (WriterT String IO) ()
getConfig2 = do
hostM <- getHost2 -- no need to call fromReader
portM <- getPort2 -- no need to call fromReader
... -- same as getConfig``````

We can see that this solution is a lot easier with less work to do. We just needed to add a Monad type constraint to the getHost2 and getPort2 functions. We also have no need for the fromReader function which is a bonus! We can also call the readWriteConfig function with getConfig2 instead of getConfig and it all works:

``````readWriteConfig2 :: IO ()

The complete Solution

``````module Config (readWriteConfig) where

import Text.Printf (printf)
import qualified Data.Map.Lazy as Map
import Data.List (intercalate)
import Data.Functor.Identity (Identity, runIdentity)
import Prelude hiding (log)

type Config = Map.Map String String

serverConfig :: Config
serverConfig = Map.fromList [("host", "localhost"), ("port", "7654")]

getHost :: Reader Config (Maybe String)
getHost = do
return (Map.lookup "host" config)

getPort :: Reader Config (Maybe Int)
getPort = do
return (Map.lookup "port" config >>= readMaybe)

log :: (Monad m, MonadTrans t, Monoid w) => w -> t (WriterT w m) ()
log = lift . tell

getConfig :: ReaderT Config (WriterT String IO) ()
getConfig = do
let host = maybe "-" id hostM
port = maybe "-" show portM
_ <- log "\nConfig"
_ <- log "\n======"
_ <- log (printf "\nhost: %s" host)
_ <- log (printf "\nport: %s" port)
return ()

getHost2 = do
return (Map.lookup "host" config)

getPort2 = do
return (Map.lookup "port" config >>= readMaybe)

getConfig2 :: ReaderT Config (WriterT String IO) ()
getConfig2 = do
hostM <- getHost2
portM <- getPort2
let host = maybe "-" id hostM
port = maybe "-" show portM
_ <- log "\nConfig"
_ <- log "\n======"
_ <- log (printf "\nhost: %s" host)
_ <- log (printf "\nport: %s" port)
return ()

## A Tale of At Least Two Monads

A Monad is based on a type constructor:

``(* -> *)``

which has one type hole; it creates a type when given a type. A simple example is the Maybe Monad:

``Maybe :: * -> *``

While we can create a Monad instance for the Maybe type constructor, a specific Maybe instance like Maybe String can’t have one because it has no type holes:

`````` Maybe         :: * -> *
(Maybe String) ::      * -- no type hole``````

Each Monad Transformer is composed of at least two Monads. If we take ReaderT MT as an example, we have its definition as:

``ReaderT r m a``

where ReaderT r m is a Monad and m is also a Monad. If you stack Monads, in the m type variable as with a WriterT for example:

``ReaderT r (WriterT w m) a``

## Decoherence’s Example

What we’ve learned so far will help us understand the example from Decoherence I mentioned at the start of this post.

We start off by defining a data type for a Person:

``data Person = Person { name :: String } deriving Show``

We then create a few specific Person instances:

``````alex :: Person
alex = Person "Alex Fontaine"

philip :: Person
philip = Person "Philip Carpenter"

kim :: Person
kim = Person "Kim Lynch"``````

followed by a peopleDb function that returns a list of Person instances:

``````peopleDb :: [Person]
peopleDb = [alex, philip, kim]``````

We then define a process function as:

``process :: ReaderT Person (WriterT String IO) ()``

and a process’ function as:

``process' :: ReaderT Person (WriterT String IO) String``

The main difference between the above functions is that one returns a Unit return type and the other returns a String, respectively. Given that the ReaderT MT stack is almost the same as that in the previous example, it should be fairly easy to implement the above functions.

The process function is implemented as:

``````process :: ReaderT Person (WriterT String IO) ()
process = do
_ <- log \$ "Looking up Person. "
_ <- log \$ printf "Found person: %s. " p
(liftIO . putStrLn) p``````

We’ve not seen the liftIO function before. It’s defined in the MonadIO typeclass as:

``liftIO :: IO a -> m a``

which just lifts a value from the IO Monad into another Monad. In the above example, liftIO will lift a Unit value from the IO Monad (`putStrLn p`), into the ReaderT Person (WriterT String IO) Monad.

The process’ function is implemented as:

``````process' :: ReaderT Person (WriterT String IO) String
process' = do
_ <- log "Looking up Person... "
_ <- log \$ printf "Found person: %s. " p
return p``````

Let’s define a function to run the transformer stack:

``````readWritePeople :: IO ()

Let’s start by running the process function with a Person instance:

``````  result1 <- runWriterT (runReaderT process alex) -- :: ((), String)
_ <- (putStrLn . snd) result1``````

Next let’s Run the process’ function with a Person instance:

``````  result2 <- runWriterT (runReaderT process' alex) -- :: (String, String)
_ <- (putStrLn . fst) result2
_ <- (putStrLn . snd) result2``````

### Traversable

Before we look at the next invocation let’s look at the definition of the mapM function. The mapM function maps each element of a structure to a monadic action, evaluates these actions from left to right, and collects the results.

``mapM :: Monad m => (a -> m b) -> t a -> m (t b)``

t is the Traversable typeclass which has a Functor and Foldable constraint:

``class (Functor t, Foldable t) => Traversable t where``

There is also a similarly named mapM_ function:

``mapM_ :: (Foldable t, Monad m) => (a -> m b) -> t a -> m ()``

which just differs from mapM in its result:

``````mapM  :: (a -> m b) -> t a -> m (t b)
mapM_ :: (a -> m b) -> t a -> m () -- only performs a side effect``````

which it discards (returns Unit). This is useful when you don’t care about the return value and just want to perform some side effect.

Some other interesting functions on the Traversable typeclass are:

• traverse - has the same definition as mapM where the container is an Applicative instead of a Monad:
``````traverse :: Applicative f => (a -> f b) -> t a -> f (t b)
mapM     :: Monad       m => (a -> m b) -> t a -> m (t b)``````
• sequenceA - Evaluate each action in the structure from left to right, and and collect the results.
``sequenceA :: Applicative f => t (f a) -> f (t a)``
• sequence - Evaluate each monadic action in the structure from left to right, and collect the results.
``sequence   :: Monad m      => t (m a) -> m (t a)``

sequence and sequenceA are also Monadic and Applicative variants of each other:

``````sequenceA  :: Applicative f => t (f a) -> f (t a)
sequence   :: Monad m       => t (m a) -> m (t a)``````

There are also `sequence_` and `sequenceA_` variants that discard the results of the action.

### Running ReaderT MT with Multiple Inputs

Let’s use mapM to run our ReaderT stack with multiple input values:

``````  result3 <- runWriterT (mapM (runReaderT process') peopleDb) -- :: ([String], String)

let people = fst result3
log    = snd result3

_ <- mapM_ putStrLn people
_ <- putStrLn "\nWriterT log:\n"``````

The mapM function is run as follows:

1. Each runReaderT process’ is supplied a Person from the peopleDb function, which then returns a WriterT String IO String.
2. These results are then collected as a WriterT String IO [String].

Here’s how we derive the result by replacing each type parameter with the actual types:

``````mapM :: (a -> m b) -> t a -> m (t b)
-- replacing a with Person:
mapM    (Person -> m b) t Person  -> m (t b)
-- replacing t with []:
mapM    (Person -> m b) [Person]  -> m [b]
-- replacing m (the Monad) with WriterT String IO
(Person -> WriterT String IO b) -> [Person] -> WriterT String IO [b]
-- replacing b with String
(Person -> WriterT String IO String) -> [Person] -> WriterT String IO [String]
-- which returns the this result:
WriterT String IO [String]``````

The final output is:

``````Alex Fontaine
Looking up Person. Found person: Alex Fontaine.
Alex Fontaine
Looking up Person... Found person: Alex Fontaine.

Alex Fontaine
Philip Carpenter
Kim Lynch

WriterT log:

Looking up Person... Found person: Alex Fontaine. Looking up Person... Found person: Philip Carpenter. Looking up Person... Found person: Kim Lynch.``````

I hope this walk-through has made using Monad Transformers a little more approachable.

The code for these examples can be found Github.

References
